Description

ALLSPARK ULTIMATE POWER PACK



Includes:

  • AllSpark 100ah LiFePO4 battery
  • Redarc Core BCDCN1225 DCDC charger with 40A CB
  • Victron Smart shunt battery monitor
  •  50A anderson plugs for alternator and solar inputs to BCDC
  •  2 x 50A plugs for input/output power with 60A CB
  •  Switches for Cig/Dual Port Quick charge USB 3 & 4 & Fridge each with 15A CB protection
  • 200A CB for 2000w inverter connection/jump start point
  • Optional AllSpark 2000w Pure Sine Wave Inverter plus connecting busbar terminals
  • Optional Mounting tray with Cam buckle tie down straps





Specifications

SKU AS-UPP100TRAY
Brand AllSpark
Shipping Weight 24.0000kg
Shipping Width 0.400m
Shipping Height 0.335m
Shipping Length 0.650m

Outer case - 540L x 207W x 287H (Terminals on top + 33mm to height & protrusion of Circuit breakers on front panel + 25mm to length).



The mounting tray adds 4mm to the length and width of the case and 9mm on the underside for the mounting bolt indents in the base of the tray.



It weighs 21.3kg or 25.9kg with the optional 2000w inverter bolted on top.
