THE ALLSPARK SOLAR PANEL RANGE HAS BEEN DESIGNED AND DEVELOPED IN AUSTRALIA TO THE HIGHEST SPECIFICATIONS



The Allspark Glass Solar Panel range are a high quality, efficient and durable option for those in need of solar power with their impressive features and 10 YEAR MANUFACTURERS WARRANTY, they will provide reliable and long-asting solar power for years to come.



CELLS

Using A-grade monocrystalline cells with a minimum efficiency of 22.4%, these panels will produce more power for their size compared to other glass panel brands.

Designed for the Australian market, the AllSpark panels have excellent temperature tolerance, outperforming other glass panels in high temperature conditions.



CONSTRUCTION

Made from durable black aluminimum, the frames provide a sturdy base even in high vibration environments such as those experienced by offroad enthusiasts.

High quality optical quality glass is used to optimize light transmission to the cells, ensuring the highest possible output at all times.

Panels come pre-fitted with 90cm cables and MC4 connectors making for an easy and secure installation.

With a 10 year manufacturers warranty and a 25 year design life, these panels are built to the highest quality to ensure durability  and reliability even in the harshest conditions.



WHATS IN THE BOX

  • 1 x AllSpark 200W 12V Glass Solar Panel
  • 90cm cables
  • MC4 connectors for easy installation
  • 15A MC4 Solar Fuse









10 YEAR MANUFACTURERS REPLACEMENT WARRANTY!
30 DAY MONEY BACK GUARANTEE!

  • Premium quality A grade monocrystalline cells
  • Minimum 22.4% efficiency meaning more power for their size compared to other glass panel brands
  • Excellent temperature tolerance outperforming other glass panels in high temperature conditions.
  • Made with high optical quality glass optimizing light transmission to the cells.
  • Fitted with durable black aluminum frames, 90 cm cables, and MC4 connectors for easy installation.
  • Service life of 25 years and a 10 YEAR WARRANTY - a testament to their high quality construction and durability

PRODUCT SPECIFICATIONS - GLASS SOLAR PANELS

SKU AS-100SPGLG2 AS-135SPGLG2 AS-200SPGLG2 AS-135SPGL-24 AS-180SPGL-24 AS-200SPGL-24
Maximum power (Pmax) 100W 135W 200W 135W 180W 200W
Open-circuit voltage (Voc) 24.0V 48.0V 48.9V 48.0V
Voltage at Pmax (Vmp) 20.5V 41.0V 41.8V 41.0V
Short-circuit current (Isc) 5.12A 6.91A 10.24A 3.46A 4.52A 5.12A
Current at Pmax (Imp) 4.88A 6.59A 9.76A 3.30A 4.31A 4.88A
Cells Efficiency (%) 22.4% 22.7% 22.4%
The maximum system voltage 1000V DC(IEC)
Power temperature coefficient -0.38%/oC -0.35%/oC -0.38%/oC
Voltage temperature coefficient -0.36%/oC -0.275%/oC -0.36%/oC
Current temperature coefficient 0.07%/oC 0.045%/oC 0.07%/oC
Output power tolerance ±3%
Operating Temperature -40oC~85oC
DImensions (LxWxH mm) 1030 x 520 x 30 1040 x 680 x 35 1500 x 680 x 35 1040 x 680 x 35 1180 x 770 x 35 1520 x 680 x 35
Weight (kg) 6.2 8.0 10.94 8.0 10.1 10.94
Output cable 2 x diodes + 900mm/4mm2 cable + MC4 compatible
Approvals IP65
Certifications CE, ROHS, FCC, TUV, UL
Warranty 10 Yrs (Service Life 25 Years)



Specifications

SKU AS-200SPGLG2
Barcode # 0745178224185
Brand AllSpark
Shipping Weight 11.0000kg
Shipping Width 1.540m
Shipping Height 0.045m
Shipping Length 0.700m
Shipping Cubic 0.048510000m3
Unit Of Measure ea
