Description

AllSpark LiFePO4 batteries have been designed and developed by Offroad Living to meet our harsh Australian conditions.

Equipped with an exclusive advanced, next generation solid state Battery Management System (BMS) that protects your battery from damage due to extremes of Current, Voltage and temperature and ensures correctly balanced cells.  Designed to handle high vibration experienced in the Aussie outback corrugations or marine environments.

FEATURES

  • Exclusive Solid state BMS designed and developed by Offroad Living
  • Highest quality premium grade prismatic cells - resistance matched, long battery life and no voltage sag
  • 400L x 120W x 300H
  • Power a 4000W Inverter from a SINGLE BATTERY - for high power devices including coffee machines, air conditioners, toasters and kettles
  • Rapid charge at 100A
  • Connect in parallel or series
  • Equivalent usable capacity to a 320ah AGM but weighs only a quarter of the weight.
  • Jump start capability up to 500A
  • Designed to handle high vibration environments
  • 5 Year Warranty

ALLSPARK LITHIUM BATTERIES ARE THE HIGHEST SPECIFICATION LITHIUM BATTERIES ON THE AUSTRALIAN MARKET



We use only the highest quality internal components and prismatic cells, ensuring optimal balancing of each cell for maximum longevity and ultimate performance.





Equipped with an exclusive advanced, next generation solid state Battery Management System (BMS) that protects your battery from damage due to extremes of Current, Voltage and temperature and ensures correctly balanced cells.

Designed to handle high vibration experienced in the Aussie outback corrugations or marine environments.
Please note that the AllSpark slimline batteries are not waterproof.
  • Owned & run by an Aussie Family
  • Manufactured for Australian conditions





5 YEAR MANUFACTURERS REPLACEMENT WARRANTY!
30 DAY MONEY BACK GUARANTEE!

Specifications

SKU AS-10024BATLI200500SLIMG1
Barcode # 0745178224284
Brand AllSpark
Shipping Weight 22.7000kg
Shipping Width 0.560m
Shipping Height 0.290m
Shipping Length 0.340m
Shipping Cubic 0.055216000m3
RATED VOLTAGE -  25.6 VOLTS
MAX CHARGE VOLTAGE  29.2 VOLTS
CUT OFF VOLTAGE  ~20 VOLTS
RAPID CHARGE CURRENT  100A
 STANDARD CHARGE CURRENT  50A
MAX INVERTER SIZE (CONT) SINGLE BATTERY 4000w
MAX CONTINUOUS DISCHARGE  200A
PEAK DISCHARGE CURRENT  500A (5 SEC)
OPTIMUM CHARGE TEMPERATURE  <45 Deg Cel
MAXIMUM SERIES VOLTAGE  48 VOLT
MAXIMUM BATTERIES IN PARALLEL  6
DIMENSIONS  (L X W X H )  400X120X300
WEIGHT (KG)  21
